Milap 150 TON
150 TON PRESS
Industry Applications & Use Cases
Automotive Industry
Applications: Stamping, forming, and assembly of metal components such as body panels, brackets, and chassis parts.
Use Cases: High-volume production of automotive parts requiring precision and repeatability.
Aerospace Industry
Applications: Forming and shaping of lightweight metal alloys for aircraft components.
Use Cases: Manufacturing of parts like wing spars, fuselage frames, and engine mounts.
Energy Sector
Applications: Forming and assembly of components for power generation equipment.
Use Cases: Production of parts such as turbine blades, generator housings, and structural supports.
Molds and Dies Manufacturing
Applications: Precision forming of mold bases and die components.
Use Cases: Fabrication of molds for injection molding, die-casting, and stamping processes.
General Engineering
Applications: Bending, punching, and forming of various metal parts.
Use Cases: Production of structural components, brackets, and other general-purpose metal parts.
The Milap 150 TON press machine is designed to meet the rigorous demands of these industries, offering robust performance and precision in metal forming applications.
Parameter | Value |
Machine Type | H-Frame Power Press |
Capacity | 150 Tons |
Bed Area (L x F-B) | 650 mm x 750 mm |
Distance Between Bed & Ram (SUAU) | 450 mm |
Slide Stroke Length | 125 mm |
Slide Adjustment | 50 mm |
Shank Hole Diameter | 55 mm |
Slide Strokes (RPM) | 35 |
Main Motor Power | 15 HP / 1440 RPM |
Motor Pulley Diameter | B-7 |
Height from Floor to Top of Bolster | 800 mm |
Bed Opening Diameter | 225 mm |
Required Air Pressure for Pneumatic Clutch | 5.5 kg/cm² |
Machine Weight | Approximately 5,100 kg |
