WASINO PUX-25 TON PRESS
25-ton C-frame single-crank press.
What it can do
Stamping / Blanking → Cutting sheet metal into small parts.
Piercing / Punching → Making holes or slots in thin sheets.
Bending / Forming → Light forming of brackets, clips, washers, connectors.
Coining / Embossing → Adding small features or surface designs.
Progressive Die Work (small scale) → With high stroke speed (~120 spm), it can run progressive dies for small precision parts.
Typical Components Made on a 25-ton Press
Electrical & electronic parts (connectors, terminals, contact pins).
Small automotive parts (washers, clips, spring plates, nameplates).
Hardware items (hinges, latches, small brackets).
Consumer products (metal buttons, battery contacts, small stamped parts).
Specification | Typical Value |
Capacity | 25 tons |
Stroke Length | 80 mm |
Stroke Speed (SPM) | 45–120 spm (model-dependent) |
Die Height (Max) | 220 mm |
Slide Adjustment | 50 mm |
Slide (Ram) Area | 250 × 200 mm |
Bolster (Bed) Size | 550 × 300 mm |
Safety Features | Light guard / curtains available |
